CLASS
D400
STD
EN124:2015
MATERIAL
Ductile Iron QT500-7
FINISH
Bitumen coated
Handmade Ductile Iron Manhole Cover
Hand-cast ductile iron manhole cover and frame in round, square, and oval profiles, available across load classes B125–F900 per BS EN124-2:2015. Hand moulding gives flexibility on non-standard sizes, tread patterns, and cast markings at lower tooling cost, while the machined seating stays anti-noise and anti-rock — with an anti-theft, self-sealing hinge.
Available specifications
| SKU | Clear opening (mm) | Outer diameter (mm) | Frame depth (mm) | Weight (kg) | Hinge type | Notes |
|---|---|---|---|---|---|---|
| DI-HM-D400 | 360 | 550 | 55 | 28 | Hinged | Ø400 cover / Ø550 frame |
| DI-HM-D500 | 450 | 605 | 50 | 25 | Hinged | Ø500 cover / Ø605 frame |
| DI-HM-D600 | 550 | 700 | 70 | 32 | Hinged | Ø600 cover / Ø700 frame |
| DI-HM-D630 | 590 | 800 | 90 | 45 | Hinged | Ø630 cover / Ø800 frame |
| DI-HM-D640 | 600 | 850 | 100 | 74 | Hinged | Ø640 cover / Ø850 frame |
| DI-HM-D400-600 | 600 | 780 | 100 | 65 | Hinged | — |
| DI-HM-D650 | 600 | 845 | 185 | 80 | Hinged | Ø650 cover / Ø845 frame · deep frame |
| DI-HM-D700-DL | 610 | 875 | 100 | 85 | Hinged | Ø700 cover / Ø875 frame · double-layer |
| DI-HM-D680 | 650 | 780 | 50 | 28 | Hinged | Ø680 cover / Ø780 frame |
| DI-HM-D700 | 650 | 870 | 90 | 65 | Hinged | Ø700 cover / Ø870 frame |
| DI-HM-D730 | 680 | 930 | 190 | 94 | Hinged | Ø730 cover / Ø930 frame · deep frame |
| DI-HM-D740 | 690 | 970 | 100 | 85 | Hinged | Ø740 cover / Ø970 frame |
| DI-HM-D750 | 700 | 750 | 100 | 95 | Hinged | Ø750 cover / Ø750 frame |
| DI-HM-D400-700 | 700 | 900 | 100 | 95 | Hinged | — |
| DI-HM-D800 | 760 | 980 | 90 | 72 | Hinged | Ø800 cover / Ø980 frame |
| DI-HM-D900 | 860 | 1080 | 90 | 108 | Hinged | Ø900 cover / Ø1080 frame |
| DI-HM-D1000 | 940 | 1120 | 80 | 120 | Hinged | Ø1000 cover / Ø1120 frame |
Custom & OEM manufacturing
Every cover, grating, and frame is made to order. Send us your dimensions, load class, tread pattern, surface coating, and cast markings — including your city name or utility logo — and we cast exactly to your drawing or tender specification.
Certifications
EN124
